EvoMotion 5-60S piston pump

EvoMotion 5-60S piston pump Low-pressure piston pump Low-pressure feed pump for Airspray applications with high-viscosity material or long hose lines. Up to 40 bar and 3.6 L/ min. DATASHEET Operating pressure 40 bar, 580 PSI Volumetric flow per double stroke 60 cm³ / DS, 3, 66 in³ / DH Material inlet A– M36x2 Material outlet I– G 3/ 8“ Air inlet connection 8 mm Air inlet pressure 2, 5 – 8, 0 bar, 36 – 116 PSI Material temperature 5 - 80 ° C, 41 - 176 ° F Ambient temperature 5 – 60 ° C, 41 – 140 ° F Material pH 3.5 – 9 pH Max. material pressure at pump inlet 20 bar, 290 PSI Weight 13, 0 kg, 28.7 lb
